Fully insulated flat plug sleeves made of CuZn (brass) provide a reliable connection for fine-stranded conductors with a copper inner sleeve. The electroplated tin-plated surface provides corrosion protection and ensures a durable, stable electrical connection. The insulation is made of PA (polyamide, nylon), halogen-free.
The connectors are designed for strain-relieved connections, and Easy Entry allows for quick and easy insertion of the conductor. Temperature resistance: -60 °C to +105 °C, 600 V max. Technical data: Nominal cross-section (mm²): 4 – 6 | Insulation color: yellow | Plug dimensions: 4.8 x 0.5 | D1: 3.4 | A: 13.0 | D2: 6.7 | L2: 7.5 | L: 22.0 | UL tested: no | Weight per 100 pieces: approx. 0.19 kg | PU/unit: 100.
EAN: 4021103802700
