Fully insulated flat plug sleeves made of CuZn (brass) provide a reliable connection for fine-stranded conductors with a copper inner sleeve. The electroplated tin surface provides corrosion protection and ensures a durable, stable electrical connection. The insulation is made of PA (polyamide, nylon), halogen-free.
The connectors are designed for strain-relieved connections, and Easy Entry allows for quick and easy insertion of the conductor. Temperature resistance: -60 °C to +105 °C, 600 V max. Technical data: Nominal cross-section (mm²): 0.5 – 1 | Insulation color: red | Plug dimensions: 6.3 x 0.8 | D1: 1.7 | A: 11.0 | D2: 4.0 | L2: 7.5 | L: 22.0 | UL tested: yes | Weight per 100 pieces: approx. 0.12 kg | PU/unit: 100.
EAN: 4021103802403
| SKU Code | Price (EUR) | Buy | Stock | Cross section | Plug size | Weight | |
|---|---|---|---|---|---|---|---|
| 180240 | €16.05 | 0.5 - 1 mm² | 6.3 x 0.8 mm | 1.2g | |||
| 180241 | €24.20 | 0.5 - 1 mm² | 2.8 x 0.5 mm | 0.8g | |||
| 180242 | €15.99 | 1.5 - 2.5 mm² | 6.3 x 0.8 mm | 1.3g | |||
| 180243 | €24.06 | 0.5 - 1 mm² | 2.8 x 0.8 mm | 1g | |||
| 180244 | €24.20 | 0.5 - 1 mm² | 4.8 x 0.5 mm | 0.9g | |||
| 180245 | €24.20 | 0.5 - 1 mm² | 4.8 x 0.8 mm | 0.9g | |||
| 180246 | €24.20 | 1.5 - 2.5 mm² | 2.8 x 0.5 mm | 1g | |||
| 180247 | €24.20 | 1.5 - 2.5 mm² | 2.8 x 0.8 mm | 0.9g | |||
| 180248 | €24.20 | 1.5 - 2.5 mm² | 4.8 x 0.5 mm | 1g | |||
| 180249 | €24.20 | 1.5 - 2.5 mm² | 4.8 x 0.8 mm | 1g | |||
| 180270 | €28.44 | 4 - 6 mm² | 4.8 x 0.5 mm | 1.9g | |||
| 180272 | €28.44 | 4 - 6 mm² | 4.8 x 0.8 mm | 1.9g | |||
| 180274 | €19.05 | 4 - 6 mm² | 6.3 x 0.8 mm | 1.9g |
