GEAR HEAD LATHE WITH READOUT

Name: GEAR HEAD LATHE WITH READOUT
Brand: FERVI
SKU: T076/400V3A
Price: 1289996000.0 VND
Availability: OutOfStock

★ 0.0 (0 reviews) • Sold 0

Imported from: Italy

WITH 2 SPEED MOTOR AND 3 AXIS READOUT, SEMI NORTON GEAR BOX. WITH CAST IRON MONOBLOC BASE.

SKU: T076/400V3A

1.289.996.000 đ

Stock status: Hết hàng

Price includes VAT

Download PDF catalog

Description

WITH 2 SPEED MOTOR AND 3 AXIS READOUT, SEMI NORTON GEAR BOX. WITH CAST IRON MONOBLOC BASE.

Specification	Value
Centers height	280 mm
Max swing over the bed	560 mm
Max swing over the cross slide	355 mm
Max swing over the gap	785 mm
Tool height	25 mm
Distance between centers	1500 mm
Spindle bore	80 mm
Spindle nose Camlock	Camlock D1-8
Spindle bore taper MT	7
Spindle speed	(12) 25 - 1600 rpm
Longitudinal feeds	(35) 0,059 - 1,646 mm/rev
Cross feeds	(35) 0,020 - 0.573 mm/rev
Metric threads	(47) 0,2 - 14 mm
Inch threads	(60) 2 - 112 TPI
Tailstock taper MT	5
Motor	400 V 50 Hz 7,5 kW
Cooling pump	400 V 50 Hz 90 W
Dimensions	3340 x 1150 x 1610 mm
Net weight	2600 kg
Packaging dimensions	3460 x 1250 x 1810 mm
Gross weight	2600,00 kg
EAN Code	8012667432263
